732B/734A
Instruction Manual
6-16
Table 6-3. A1 Front Panel PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C100 CAP,POLYES,0.1UF,+-10%,50V 649913 1
C101 CAP,TA,1UF,+-20%,35V 697417 1
C102 CAP,POLYES,0.2UF,+-10%,50V 706028 1
CR100-103 LED,RED,T1,2.0 MCD 875666 4
CR104 DIODE,SI,100 PIV,5.0 AMP 483701 1
CR105 DIODE,SI,BV=125V,IO=150MA,500MW 272252 1
E100 SURGE PROTECTOR,230V,+-15% 500363 1
MP100-103 SPACER,LED MOUNT,PVC,.375 887067 4
Q100 * TRANSISTOR,SI,N-DMOS PWR FET, TO-92 782565 1
R100-103 RES,MF,10K,+-1%,0.125W,100PPM 168260 4
R104 RES,MF,1M,+-1%,0.125W,100PPM 268797 1
R105 RES,MF,590,+-1%,0.125W,100PPM 261883 1
R106 RES,CF,100K,+-5%,0.25W 348920 1
U100 * IC,CMOS,TIMER 742254 1
VR101 * ZENER,TRANS SUPPRESSOR,11V,5% 912381 1
W104 CABLE, FRONT PANEL 869149 1
