Fluke 732B - Page 106

732B/734A
Instruction Manual
6-20
Table 6-4. A5 Power Supply PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
SW501 SWITCH,PUSH-BTN,SPDT,MOMENTARY,RT ANG 743252 1
SW502 SWITCH,SLIDE,SPDT 453365 1
TP1,2,501 502,
504, 507-509,
512,513
JUMPER,WIRE,NONINSUL,0.200CTR 816090
816090
816090
9
U500,U504 * IC,VOLT REG,ADJ,POS,LOW DROPOUT 876537 2
U501,U507 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 2
U505 * IC,10.00V,65 PPM TC,VOLTAGE REF 876532 1
U506 * IC,OP AMP,MICROPOWER,DUAL,8 PIN 876495 1
U509 * IC,CMOS,QUAD 2 INPUT NAND GATE 453241 1
U511 * IC,SWITCHED CAP VOLT CONV W/REG,8 DIP 876800 1
U513 * ISOLATOR,OPTO,LED TO DARLINGTON,DUAL 640664 1
U514,515 * ISOLATOR,OPTO,LED,TO XSISTR 6N135 354746 2
U516 * IC,CMOS,DUAL D F/F,14 PIN DIP 340117 1
VR501 * ZENER,UNCOMP,43V,5%,3MA,0.5W 851584 1
VR502 * ZENER,UNCOMP,13.0V,5%,9.5MA,0.4W 110726 1
VR503 * ZENER,UNCOMP,15.0V,5%,1.0MA,0.4W 352377 1
VR504 * ZENER,UNCOMP,5.4V,5%,0.03MA,4.0W 680504 1
VR508 * ZENER,UNCOMP,20.0V,5%,6.2MA,0.4W 180463 1
VR509 * ZENER,UNCOMP,18.0V,5%,7.0MA,0,4W 327973 1
XSW501 SWITCH ACC,CAP,BLK 876891 1
