Fluke 732B - Page 82

732B/734A
Instruction Manual
5-12
REPLACE AS MODULE
ONLY, NO USER
SERVICEABLE PARTS
10V OUTPUT ADJ.
(PPM)
0.1 1.0 10 100
!
732B DC STANDARD
AC PWR
IN CAL
CHARGE
LOW BAT
10V
1.018V
CHASSIS
GUARD
1.018V COM
10V COM
SERIAL NUMBER
REPLACE AS MODULE
ONLY, NO USER
SERVICEABLE PARTS
10V OUTPUT ADJ.
(PPM)
0.1 1.0 10 100
!
732B DC STANDARD
AC PWR
IN CAL
CHARGE
LOW BAT
10V
1.018V
CHASSIS
GUARD
1.018V COM
10V COM
SERIAL NUMBER
A.
B.
CAUTION
TO AVOID LOSS OF
CALIBRATION, LEAVE AC
LINE CORD PLUGGED IN.
DISCONNECT
BATTERY CABLE
(4 POSITION 2 WIRES)
BATTERY BRACKET
HOLD DOWN SCREWS
(4 PLACES)
KEY STUDS GO
INTO KEY SLOTS
(2 PLACES)
DISCONNECT
RED WIRE
(BATTERY TERMINAL)
KEY STUDS
(2 PLACES)
k22f.eps
Figure 5-4. Replacing the Battery
