Fluke 8842A User Manual

8842A
Instruction Manual
7-10
Table 7-2. A1 Main PCA
Reference
Designator
Description Fluke Stock
No
Tot Qty Notes
AR701 REF AMP SET 759290 1
C101-103,C311 CAP,POLYPR,0.1UF,+-10%,160V 446781 4
C104,C105,C205- CAP,CER,0.22UF,+80-20%,50V,Z5U 733386 15
209,C304,C305, 733386
C315,C404,C604, 733386
C606,C609,C610 733386
C202,C203,C617, CAP,CER,0.01UF,+80-20%,50V,Z5V 697284 4
C618 697284
C204,C602,C608, CAP,TA,1UF,+-20%,35V 697417 4
C612 697417
C210 CAP,CER,1000PF,+-20%,50V,X7R 697458 1
C301,C302 CAP,POLYPR,0.33UF,+-10%,160V 520346 2
C303 CAP,POLYES,0.33UF,+-10%,50V 715284 1
C306 CAP, POLYPR,0.22UF,+-10%,160V 446799 7
C307 CAP, POLYPR,4700PF,+-10%,63V 721662 t
C308 CAP,POLYPR,0.47UF,+-10%,160V 446807 1
C309 CAP,CER,120PF,+-5%,50V,C0G 721142 1
C310 CAP,CER,120PF,+-5%,50V,C0G 721142 1
C312 CAP,POLYES,0.001UF,+-10%,50V 720938 1
C314 CAP,POLYPR,0.047UF,+-10%,160V 446773 1
C402 CAP,CER,330PF,+-5%,50V,C0G 697441 1
C403 CAP,POLYES,0.47UF,+-10%,50V 697409 1
0601 CAP,AL,6800UF,+/-20%,16V 478784 1
C603 CAP,AL,330UF,+50-20%,100V 484436 1
C605,C607 CAP,AL,470UF,+-20%,50V,SOLV PROOF 747493 2
C611 CAP,AL,100UF,+50-20%,50V 649731 1 1
C701 CAP,CER,270PF,+-5%,50V,C0G 658898 1
CL301 * I-REG DIODE,0.43MA,20%,SEL,TO-0226AC 707836 1
CR101,CR102, ZENER,UNCOMP,3.9V,10%,20.0MA,0,4W 113316 10
CR201,CR202, 113316
CR306,CR307, 113316
CR309,CR311- 113316
313 113316
CR103,CR104, * ZENER,UNCOMP,7.5V,5%,20.0MA,0.4W 256446 3
CR613 * 256446
CR105,CR106, * DIODE,SI,BV=75V,10=150MA,500MW 203323 12
CR203-206, * 203323
CR301,CR302, * 203323
CR401,CR404, * 203323
CR615,CR701 * 203323
CR303 * ZENER,UNCOMP,10.0V,5%,12.5MA,0.4W 246611 1
CR304,CR305 * ZENER,UNCOMP,6.8V,5%,20.OMA,0.4W 260695 2
CR308,CR310 * ZENER,UNCOMP,24.0V,5%,5.2MA,0.4W 267807 2
CR402,CR403 DIODE,SI,1K PIV,1.0AMP 707075 2
CR405 * ZENER,UNCOMP,5.1V,5%,20.0MA,0 159798 1
CR601-606, DIODE,S1,100 PIV,1 AMP 742874 70
CR608-611 742874
CR607,CR612 * ZENER,UNCOMP,6.2V,5%,20.0MA,0.4W 325811 2
CR614 * ZENER,UNCOMP,8.2V,5%,20.0MA,0.4W 386771 1
CR616 ZENER,UNCOMP,56.0V,5%,2.2MA,0.4W 187757 1
CR617 ZENER,UNCOMP,8.2V,5%,20.OMA,0.4W 386771 1
H1,H51 RIVET,S-TUB,OVAL,STL,.118,.156 103424 2
H3 NUT,BROACH,STL,4-40 380196 1
H5 NUT,HEX,STL,4-40 110635 1
H6 SCREW,PH,P,SEMS,STL,6-32,.250 178533 1
H12 SCREW,PH,P,SEMS,STL,4-40,.250 185918 1
J201 HEADER,2 ROW,.100CTR,20 PIN 706986 1
J202 CABLE ASSY,FLAT,10 CONDUCT,6.0 714022 1

Fluke 8842A Specifications

General

Maximum Voltage	1000 V
Maximum Current	2 A
Operating Temperature	0°C to 50°C
Weight	2.5 kg
DC Voltage Range	100mV to 1000V
DC Current Range	0 to 2 A
AC Current Range	0 to 2 A
Frequency Range	20 Hz to 20kHz
Basic Resistance Accuracy	0.01%
Dimensions	216mm x 88mm x 280mm
Resistance Range	200 Ω to 20 MΩ
