Fluke 8842A User Manual

8842A
Instruction Manual
809-4
809-3. OPERATING INSTRUCTIONS
For operating instructions, refer to Section 2. For ac measurement considerations, refer to
Section 4.
809-4. MAINTENANCE
All service information regarding Option -09 is contained in Section 6. The theory of
operation is contained in Section 5.
809-5. LIST OF REPLACEABLE PARTS
A list of replaceable parts for the True RMS AC printed circuit assembly (PCA) is given
in Table 809-1. Refer to Section 7 for ordering information.
CAUTION
The symbol * indicates a device that may be damaged by static
discharge.

Fluke 8842A Specifications

General

Maximum Voltage	1000 V
Maximum Current	2 A
Operating Temperature	0°C to 50°C
Weight	2.5 kg
DC Voltage Range	100mV to 1000V
DC Current Range	0 to 2 A
AC Current Range	0 to 2 A
Frequency Range	20 Hz to 20kHz
Basic Resistance Accuracy	0.01%
Dimensions	216mm x 88mm x 280mm
Resistance Range	200 Ω to 20 MΩ
