8842A
Instruction Manual
7-12
Table 7-2. A1 Main PCA (cont)
Reference
Designator
Description Fluke Stock
No
Tot Qty Notes
R413 RES,MF,4.99M,+-1%,0.125W,100PPM 715060 1
R414 RES,MF,576K,+-1%,0.125W,l00PPM 344291 1
R416 RES,MF,100,+-1 %,0.125W,25PPM 460527 1
R601 RES,CF,560,+-5%,0.25W 385948 1
RV301,RV401-404 VARISTOR,390V,+-10%,1MA 697383 5
RV601 VARISTOR,430V,+-10%,1.0MA 519355 1
S201 SWITCH,PUSHBUTTON,DPDT,PUSH-PUSH 875703 1
S601 SWITCH,PUSHBUTTON,DPDT,PUSH-PUSH 453605 1
T201,T202 TRANSFORMER, PULSE 660589 2
T601 TRANSFORMER, POWER 803270 1
TP101-105,TP201, TERM,FASTON,TA8,.110,SOLDER 512889 25
TP202,TP204-207, 512889
TP301-304,TP401, 512889
TP403,TP601-605, 512889
TP607-609 512889
U102,U702 * IC,OP AMP,DUAL,LO OFFST,VOLT,LO-DRIFT 685164 2
U103 * IC,OP AMP,LO-OFF VOLTAGE,LO-DRIFT 685156 1
U201 * IC,BIPLR,BCHNL DRIVER 685412 1
0203 * IC,LSTTL,HEX INVERTER 393058 1
U204,U305 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 2
U208 * IC,LSTTL,3-8 LINE DCDR W/ENABLE 407585 1
U211 * IC,LSTTL,QUAD 2 INPUT OR GATE 393108 1
0213 * IC,LSTTL,8BIT ADDRSABLE LATCH,W/CLR 419242 1
U215,U217,U218 * IC,BIPLR,8CHNL FLOURSCNT DISPLY DRIVR 685537 3
0216 * IC,LSTTL,BCD TO 7 SEGMENT DCDR/DRVR 697730 1
U219 * IC,CMOS,OCTL D F/F W/3-STATE,+EDG TRG 585364 1
0221 * IC,LSTTL,HEX INVERTER W/SCHMT TRIG 483180 1
U301-303,U402 * IC CMOS, QAS, PLASTIC, HIGH, B GRADE 700013 4
U304 * IC,OP AMP,FET,LO NOISE,PRECISIION,8DIP 780759 1
0306 * IC,OP AMP,SPECIAL,LOW DRIFT,TO-99 650713 1
U307 * IC,OP AMP,JFET IN,COMPENSTD,8 PIN DIP 418780 1
0401 * IC,OP AMP,LO-OFFSET VOLTAGE,LO-NOISE 605980 1
U403 * IC CMOS, QAS, PLASTIC, HIGH, A GRADE 803478 1
U404 * IC,OP AMP,GENERAL PURPOSE,8 PIN 478107 1
VR601 * IC,VOLT REG,FIXED,+5 VOLTS,1.5 AMPS 428847 1
VR602 * IC,VOLT REG,FIXED,+24 VOLTS,1.5 AMPS 604074 1
VR603 * IC,VOLT REG,FIXED,+15 VOLTS,1.5 AMPS 413187 1
VR604 * IC,VOLT REG,FIXED; 15 VOLTS,1.5 AMPS 413179 1
VR605 * IC,VOLT REG,FIXED, 24 VOLTS,1.5 AMPS 418251 1
W1,W8 WIRE ASSEMBLY, GUARD CROSSING 684399 2
W2,W9 WIRE ASSY, GUARD CROSSING 728840 2
W5 HARNESS, ANALOG FRONT 765297 1
W6 HARNESS, ANALOG REAR 765305 1
W10 CABLE, LINE VOLTAGE-GROUND 873740 1
W11 CABLE, LINE VOLTAGE-LINE 873745 1
W12 CABLE, LINE VOLTAGE-NEUTRAL 873752 1
XU101,XU102, SOCKETJC,40 PIN,DUAL WIPE,RET 756668 3
XU212 756668
XU220 SOCKET,IC,24 PIN,DUAL WIPE,BEAM TYPE 756650 1
XU222 756353 1
Y201 CRYSTAL,8.OOMHZ QUARTZ HC-18U 707133 1
Z101 RNET,MF,HERM,SIP,8842 A TO D CONV 755983 1
Z301,Z303 * RNET,MF,HERM,SIP,8842 LO V DIVIDER 755934 2
Z302 * RNET,MF,HERM,SIP,8842 HI V DIVIDER 756130 1
Z304,Z402 * RNET,CERM,SIP,8840 HI V PROTECT 715789 2
Z401 * RNET,MF,HERM,SIP,LO V 1 SOURCE 755884 1
Z702 * RNET,MF,HERM,SIP,8842 LO V DIVIDER 756080 1
1. FUSIBLE RESISTOR. TO ENSURE SAFETY, USE EXACT REPLACEMENT ONLY.
