Physical Features
9
A
LCD display with backlight.
B J K: The softkeys provide functions related to
the current screen. The current functions are shown on
the screen above the keys.
C P: Starts the currently selected test.
D H: Enter key selects the highlighted item from a
menu. Enters and exits edit mode when making
selections and editing text.
E Rotary switch selects the tester’s modes.
F USB port for uploading test reports to a PC and
updating the tester’s software. See “Uploading Results
to a PC” on page 62.
G L: On/off key.
H B C A D: Arrow keys for navigating through
screens and incrementing or decrementing
alphanumeric values. For navigation, use
B C to page
up and down. Use SHIFT and
A or D to go to the
top or bottom of a list.
I G: Toggles the backlight between dim and bright
settings.
J I: Exits the current screen. Also exit edit mode when
making selections and editing text.
K F-connector for connecting to 75 Ω coaxial cable.
L Modular jack for connecting to telephone and twisted
pair network cable. The jack accepts 8-pin modular
(RJ45) and 6-pin modular (RJ11) connectors.
M Wiremap adapter with F-connector and modular jack.
See “Using the Wiremap Adapter and Remote ID
Locators” on page 10 for details.
N Remote ID locator (optional) with F-connector and
modular jack. See “Using the Wiremap Adapter and
Remote ID Locators” on page 10 for details.
Figure 2. Features (cont.)
