Appendix A: Diagnosing Cabling Faults
Appendix A lists the typical causes of cable test failures.
Wire map: open
• Wires connected to wrong pins at connector or punchdown blocks
• Faulty connections
• Damaged connector
• Damaged cable
• Wrong pairs selected in setup
• Wrong application for cable
-continued-
