CableIQ Qualification Tester
Users Manual
62
Memory Functions
The tester can store up to 250 Autotest results in non-
volatile memory. Other tests cannot be saved.
Viewing Saved Results
1 Turn the rotary switch to RESULTS.
2 Use AD, B C, or SHIFT + AD to move
through the list and highlight a test to view.
3 Press
H or J to view the highlighted test.
Deleting Results
1 Turn the rotary switch to RESULTS.
2 To select one result to delete, use
AD, B C, or
SHIFT + AD to move through the list and
highlight the test.
3 Press
K Del.
4 Use
AD to select Delete Selected Test or Delete
All Tests; then press H or K Del.
5 If you selected Delete All Tests, press
J to confirm
your choice.
Uploading Results to a PC
CableIQ Reporter software lets you upload Autotest
results to a PC, view results, and customize and print test
reports.
To upload results to a PC:
2 Turn on the tester.
3 Connect the tester to the PC using the USB cable
provided.
4 On the CableIQ Reporter toolbar, click
; then
select CableIQ.
Details about using CableIQ Reporter software are
provided in the online help available under Help on the
CableIQ Reporter menu.
1 Install the latest version
of CableIQ Reporter on your
PC. CableIQ Reporter is available on the Fluke
Networks website.
