Specifications
69
General Specifications
Test connectors Shielded 8-pin modular jack accepts 8-pin modular (RJ45) and 4-pin modular (RJ11) plugs.
F-connector for coaxial cable
Power Battery type: 4 AA (NEDA 15A, IEC LR6) alkaline batteries
Battery life: 20 hours of typical use, without backlight
Other compatible battery types: 4 AA photo lithium, NIMH, NICAD
Serial interface USB mini-B 5-pin connector
Dimensions and weight 7 in x 3.5 in x 1.75in 17.8 cm x 8.9 cm x 4.5 cm
1.2 lb (0.55 kg)
Display 2.5 in (5.6 cm) 128 dots wide by 128 dots high monochrome LCD with backlight
Service period Fluke Networks recommends the tester’s operation be verified at a Fluke Networks
authorized service center every 12 months.
