CableIQ Qualification Tester
Users Manual
70
Performance Specifications
Qualification Autotests 1000BASE-T, 100BASE-TX, 10BASE-T, VoIP, wiremap only, 1394b S100 (Firewire), Telco,
75 Ω coaxial
Autotest speed 4 seconds (typical)
Autotest storage Up to 250 Autotests
Length test Range: 300 m (1000 ft)
Resolution: 0.1 m ( 0.1 ft)
Typical accuracy: ± 4% or 2 ft whichever is greater. NVP uncertainty is an additional error
Calibration: User-settable NVP for twisted pair and coax. Can determine actual NVP with
known length of cable.
Wiremap test Detects single-wire faults. MultiMap function reports wiremaps for up to 7 remote ID
adapters. Draws proportional wire length to breaks. Detects split pairs.
Signal performance Measures crosstalk and return loss characteristics in frequency range of 1-100 MHz.
Voltage protection Protected against ISDN, PoE and telephone voltages.
