Wire map: split pair
Wires connected to wrong pins at connector or punchdown block.
Wire map: reversed pairs
Wires connected to wrong pins at connector or punchdown block.
Wire map: crossed pairs
• Wires connected to wrong pins at connector or punchdown block.
• Mix of 568A and 568B wiring standards (12 and 36 crossed).
• Crossover cables used where not needed (12 and 36 crossed).
Wire map: short
• Damaged connector
• Damaged cable
• Conductive material stuck between pins at connector.
• Improper connector termination
• Wrong application for cable
-continued-
