Fluke CableIQ - Autotest Results for Coaxial Cabling; Interpreting Coaxial Autotest Results

CableIQ Qualification Tester
Users Manual
34
avv41.bmp avv43.bmp
The cabling passed the Autotest. The cabling is 80.2 m long,
with a wiremap adapter at the far end.
The cabling passed the Autotest, but could not be
qualified because a far-end adapter was not used. The
tester cannot verify continuity to the end of the cabling.
-continued-
Figure 14. Autotest Results for Coaxial Cabling
