The Analyzer
Figure 1 shows the top of the Analyzer.
Figure 1. Top of the Analyzer
 Touchsceen LCD
 Flow exhaust
 Flow inlet
D Low pressure + and -
E High pressure and vacuum
F Ultra-low pressure (VT900)
G Ultra-low flow + and - (VT900)
H Power button
FLOW
INLET
±
300 lpm
FLOW
EXHAUST
ULTR A
LOW FLOW
LOW
PRESSURE
ULTRA
LOW PRESSURE
0 TO 10 mbar
HIGH
PRESSURE
750 ml /min 160 m ba r0.8 TO 10 bar
GAS FLOW ANALYZER
VT900
4
5
7
6
8
3
2
1
