15. Main menu
The main menu can be accessed by touching the settings
icon at the bottom of the main screen.
The main menu is organized in horizontal pages. Each
page contains up to 12 icons representing 12 different
functions.
The white balls in the bottom tray indicate which menu page
is displayed. The big white ball represents the currently
displayed page.
To display the next page, touch the current page anywhere
on its right part and slide it to the left.
To display the previous page, touch the current page
anywhere on its left part and slide it to the right.
To enter a function, simply touch its corresponding icon.
To return to the main screen, touch the back button
in the bottom tray.
主菜单
Main menu page 1 Main menu page 2
点触屏幕下方的设置图标 进入主菜单。
主菜单有两个平行页面组成，每个页面包含最多12个图标，
分别代表12个不同的功能。
屏幕底部的白色球体表示显示的菜单页面，大的白色球
体代表当前显示的页面。
点触当前页的任何位置由右向左滑动可显示下一页。
点触当前页的任何位置由左向右滑动可显示上一页。
点触相对应的图标可进入该功能。
点触底部的文件盘上的返回图标 可返回主屏幕。
16. Top tray
顶部状态栏
主菜单第一页 主菜单第二页
The top tray of the screen constantly displays the main status of the whole system.
屏幕顶部一直显示整个系统的主要状态。
displays the signal strength received by the vehicle. The strongest signal is
represented with 5 bars. When the signal strength is lower or equal to two bars, an
audible alarm rings.
displays the status of the receiver battery. If the voltage is too low, an audible alarm
rings and this symbol blinks. See further how to set up the receiver battery alarm
voltage.
显示接收机电池的状态。如果电压太低，可听见警报，并且这个图标将闪烁。如何设置接收
机电池低电压报警将在后文说明。
displays the status of the remote control battery. If the voltage is too low, an audible
alarm rings and this symbol blinks.
显示发射机电池的状态。如果电压太低，可听见警报，并且这个图标将闪烁。
displays the number and the name of the currently selected model.
显示当前选定的模型编号和名称。
显示模型接收到信号的强度。最强信号是5格，当信号强度等于或低于2格，将听到警报。
18
