This function displays in real time the position of the 4 servos.
The test button let the 4 servos to move slowly between their respective end points.
This allows to test the consistency of the mechanics of the model.
17.18:
Display servos
显示舵机
When the brake side operation is unnecessary with a boat and some other vehicle,
it can be disabled.
In this example, the throttle trigger is at its neutral position but since the boat mode
is activated, the throttle servo is at its low end point.
The race timer allows to measure time durations in 4 different modes. Touch the
mode button to select the race timer mode.
Up timer: this timer starts to count up from 0. It can be only started, stopped or reset
to zero.
In this example, the up timer is started.
17.19:
Race timer
计时器
Down timer: when the down timer is stopped, the wheel sets the start time from 1 to 99
minutes.
Once started, the down timer counts down toward zero. Once zero is reached, it counts
up like an up timer. Resetting a down timer sets it back to its start time.
In this example, the down timer is set to 5 minutes but is still stopped.
此功能显示4个舵机的即时位置。
点触测试按钮 让4个舵机在其最大行程内缓慢移动，可测试模型机械的一致性。
计时器可测量4种不同模式下的时间。点触模式按钮选择计时器模式。
正向计时器：从0开始计时。可进行开始，停止和复位三种操作。
如图所示：计时器已开始计时。
倒数计时器：当倒数计时器停止时，可用转轮从1分钟到99分钟设置倒数开始时间。
一旦开始，计时器向0开始计时。一旦达到0，则和正向计时器一样计时。复位倒数计时器
使倒数计时时间返回到开始设定的时间。
如图所示：倒数计时器设定到5分钟，此时倒数计时器是停止状态。
30
