The sub trims function individually adjusts the center position of each servo of the
4 channels. This is particularly useful when the servo mechanics doesnt allow an
adjustment fine enough.
Touch the channel which sub trim must me adjusted
Use the wheel to move the red needle and modify the sub trim value of the
selected channel.
The position of the corresponding channel is displayed in real time
In this example, the channel 2 (throttle) has been selected and the throttle
trigger is half braking.
The sub trim of each channel can be assigned to a trim switch.
节4个
: 2通于50%刹
The steering exponential function modifies the transfer curve between
the steering wheel and the channel 1.
Once activated, 2 buttons select which parameter value to modify:
Rate: adjust the slope of the curve. The smaller is the slope, the shorter
is the throw of the corresponding servo.
Exp.: adjust the linearity of the curve. A value of 0 corresponds to a
perfectly linear curve. A positive value decreases the sensitivity near
the neutral position and increases it on the extreme sides. A negative
value increase the sensitivity near the neutral position and decreases
it on the extreme sides The vertical dotted line displays in real time the
position of the steering wheel.The horizontal dotted line displays in
real time the steering position after the exponential function.
In this example, the exponential function is activated, the selected
parameter is exponential and is set to its maximum value.
The horizontal dotted line shows a steering wheel 20% under the
neutral position
but the horizontal dotted line indicates that the resulting servo throw is
less than 10% showing the efficiency of the exponential function.
The activation of the steering exponential function can be assigned to
a push button.The steering rate can be assigned to a trim switch
The steering exponential can be assigned to a trim switch.
和1通线
有2个
线线
线线线是0时线线
线
线
线下20%的
10%的线
17.03:
Sub trims
17.04:
Steering exponential
22
http://www.flysky-cn.com
