4. Operation Guide
After setting up, follow the instructions below to use the product.
Follow the steps below to turn on the transmitter:
1. Check to make sure that the batteries are fully charged and installed correctly.
2. Toggle the Power Switch to the ON position.
4.1 Power-on
4.2 The LED Status of the Transmitter
Attention • Operate with caution in order to avoid damage or injury.
The D1 LED of this transmitter is used to indicate the status of the transmitter, and the D2 LED is used to indicate the
status of the receiver which is in two-way binding with the transmitter, as shown in the following table:
Note: For safety always power on the transmitter before the receiver.
LED LED Status Transmitter Status Note
D1
Flash in green, orange and red
repeatedly for 2S
Standby mode (The transmitter is in normal mode
after powering on without toggling any control）
Slow ash once in red Switch to CH1
Switch channels (1 to 3~7),
used to adjust the positive
and negative direction,
Trim, and travel of CH3-
CH7 channels.
Slow ash three times in red Switch to CH3
Slow ash four times in red Switch to CH4
Slow ash ve times in red Switch to CH5
Slow ash six times in red Switch to CH6
Slow ash seven times in red Switch to CH7
Solid on in green High voltage
Transmitter voltageSolid on in orange Medium voltage
Slow ash in red Low voltage
Slow ash in green for 3S 2-in-1 mode switching
2-in-1 mode
Slow ash in green for 3S 2-in-1 mode after powering on
Two-ash-one-o in green for 3S Switching beginner mode
Beginner mode
Two-ash-one-o in green for 3S Beginner mode after powering on
Fast ash in red In binding
Binding (or Calibration,
refer to funtion description)
Solid on in red Binding is successful (or in calibration mode)
Fast ash in red & green
alternately for 2S
From one-way mode to two-way mode
One-way mode or two-way
mode switching
Fast ash in red & green
alternately for 2S
From two-way mode to one-way mode
Fast ash in red & green
alternately for 3S
In one-way after powering on
Three-ash-one-o in red Receiver is not bound or disconnected TX and RX disconnect
Red gradual light In Idle state Idle alarm
Orange gradual light In Sleep state Sleep mode
Fast ash in red for 3S Factory reset Factory reset
