FlySky FS-MG7 - Customized Definition; Steering Wheel Angle Adjustment Instruction

FS-MG7
Automatic Frequency Hopping Digital System
Website
16
7. Customized De󽗉nition
7.1 Steering Wheel Angle Adjustment Instruction
1 2 3
4 5 6
First insert a hexagonal
screwdriver into the screw hole
used to secure the steering
wheel.
Hold the side of the steering
wheel, and at the same time
turn the hexagonal screwdriver
counterclockwise until the
screw is completely loose and
remove it.
Hold the transmitter body, and
pull out the steering wheel to
remover the wheel.
Pinch the brake pad with two
󽗉ngers and take out upwardly.
As shown, put two screws into
the screw holes on both ends of
the brake pad. Use a hexagonal
screwdriver to 󽗉x the screws in
turn.
Carefully remove the sponge
from the steering wheel.
Fllow the steps below to adjust the angle of the steering wheel.
