FS-MG7
Automatic Frequency Hopping Digital System
Website
10
This function is used to adjust the travel range value of the channel.
For 2-in-1 mode, only CH1-CH4 travel range value can be adjusted. For non-2-in-1 mode, CH1-CH7 travel range value
can be adjusted.
• When the steering wheel is located in the maximum travel or minimum travel, press the ST+/- button to adjust CH1
and CH3-CH7 travel range value. By default, the CH1 travel range value is adjusted. To adjust CH3-CH7, rst switch
to the corresponding channel. When CH7 is set to rear wheel steering only, CH7 travel range value can be adjusted
by pressing the ST+/- button in CH1.
• When the throttle trigger is at the maximum or minimum travel, press the TH+/- button to adjust CH2 travel range
value.
ST+/TH+: Increase the travel value. ST-/TH-: Decrease the travel value. Travel range: 0-120%, by default, it is 100%,
the step is 5%.
When the servo setting action takes eect, the buzzer will beep once shortly in Tone 2. You can press and hold it for
quick adjustment. The buzzer will sound for seconds when it reaches the end.
5.5 D/R Setting
To reverse the output direction of the channel.
For 2-in-1 mode, it can adjust the direction of CH1 and CH2 only. For non-2-in-1 mode, it can adjust the direction of
CH1-CH7.
• When the steering wheel is at the maximum or minimum travel, press the REV button to adjust CH1 and CH3-CH7
reverse steering. Press once to switch once. By default, it adjusts the steering of CH1. To adjust the steering of CH3-
CH7, switch to the corresponding channel rstly. When only CH7 is set to rear wheel steering mode, CH7 can be
reversed by pressing the REV button under CH1. When the reverse steering action takes eect, the buzzer will beep
once shortly in Tone 1.
• When the throttle trigger is at maximum or minimum travel and the steering wheel is in the neutral position, press
the REV button to reverse CH2. To switch once, press once. When the channel reverse steering action takes eect,
the buzzer will beep once shortly in Tone 2.
This function is used to adjust the channel trim.
For 2-in-1 mode, only CH1-CH4 trim can be adjusted. For non-2-in-1 mode, CH1-CH7 trim can be adjusted.
• When the steering wheel is in the neutral position, press the ST+/- button to adjust CH1 and CH3-CH7 trim. By
default, the CH1 trim is adjusted. To adjust CH3-CH7, rst switch to the corresponding channel. When CH7 is set to
rear wheel steering only, CH7 trim can be adjusted by pressing the ST+/- button in CH1.
• When the throttle trigger is in the neutral position, press the TH+/- button to adjust the CH2 trim.
ST+/TH+: Press to increase the trim value. ST-/TH-: Press to decrease the trim value. The trim range: -120 us~120 us.
The step is 4us. By default, it is 0.
When the trim setting action takes eect, the buzzer will beep once shortly in Tone 1. You can press and hold it for
quick adjustment. The buzzer will beep twice shortly when the trim is over Neutral. The buzzer will sound once for
seconds when it reaches the end.
5.3 Channel Reverse
5.4 Trim Setting
