FS-MG7
Automatic Frequency Hopping Digital System
Website
2
2.Introduction
The FS-MG7 is a 7-channel transmitter which is compatible with the 2.4GHz ANT Automatic Frequency Hopping
Digital System, featuring compact design, comfortable to the hand, ergonomic. In addition, the ESC parameters can
be set at the transmitter side. The transmitter also has a beginner mode for beginners.
2.1 Transmitter Overview
Steering Wheel (CH1)
Switch CH4 (CH4)
REV Button
D1 LED
D2 LED
Switch CH3 (CH3）
Switch CH5 (CH5)
ST- Button
BIND Button
TH- Button
LOGO Sticker
ST+ Button
TH+ Button
Power Switch
Throttle Trigger (CH2)
Battery Compartment
4*AAA Batteries inside
Lanyard Hole
CH6 Button (CH6)
CH7 Button (CH7)
Ambient Light
RGB Color
Type-C USB Port
To Next Page
