Folger Tech FT-5 - Page 32

FT-5 User Manual Page 31
3. Insert the slider rail onto the 460mm 2020
beam. Center it on the 2020 beam and lock
the M3 screws in.
4. Repeat step 3 on the other 2020 beam. The
remaining slider rail will be used at a later
step.
5. Line up the two rails and align the sliders with
each other. Use some kapton tape to lock each
one in place. This will prevent the slides from
falling off while building and they will be cut
free later.
