Fortis 5000RT-A - Field Wiring Connection Locations

REMOVE UPPER COVER
TO ACCESS CONTROL
PANEL
POWER TERMINAL
BLOCK
CONTROL MODULE
CONTROL CABLE
CONNECTOR
REMOVE FRONT PANEL OF TELLER
UNIT (4 SCREWS) BE CAREFUL WHILE
REMOVING FRONT PANEL. THERE IS A
CABLE ATTACHED THAT GOES TO
THE DOOR POSITION SENSOR.
DOOR POSITION SENSOR
FIELD WIRING CONNECTOR
5000RT AUTO TELLER CONTROL COMPONENT
LOCATIONS
5000RT MANUAL TELLER CONTROL COMPONENT
LOCATIONS
P-19
