Fortis 5000RT-A - Teller Bend Tubing Check Valve Installation

VENTED BEND
LOCATED ABOVE
TELLER UNIT
FLEX HOSE
HOSE CLAMPS
CHECK VALVE PORT
CHECK VALVE
ASSEMBLY
FS55-0150
5000RT CHECK VALVE ASSEMBLY
WHEN INSTALLING CHECK VALE ALWAYS MOUNT SO THAT THE VALVE
FLAP IS HANGING DOWN OR IS ON TOP.
SEE ILLUSTRATIONS BELOW
OK OK NOT OK NOT OK
X
X
