A
MOUNT HEATER HERE
USING THE (4)
THREADED HOLES
REMOVE TURBINE BOX AS SHOWN
TO MAKE IT EASIER TO INSTALL HEATER
PLUG HEATER IN HERE
ROUTE HEATER CABLE
UP THRU HERE
NOTE - HEATER HAS AN INLINE
THERMOSTAT THAT WILL ONLY
TURN THE HEATER ON WHEN IT
GETS BELOW 50°f AND WILL
THEN TURN THE HEATER OFF
ONCE THE TEMPERATURE GETS
ABOVE 70°f
5000RT CUSTOMER HEATER INSTALLATION
P-30
