3. Product Description
3.2 Technical Data
3.2.1 Measurement and Sensors
Measuring Properties
Table 3: Measuring Properties
Property Value Unit
Channels 9 -
Measuring range 1545.5 … 1561.0 nm
Absolute precision
(Measuring range 1546.0 … 1558.0 nm)
50 pm
Absolute precision
(Measuring range 1545.5 … 1561.0 nm)
150 pm
Wavelength stability over the
temperature range
20 pm
Noise
1
< 1 pm
Resolution
2
< 0.01 pm
Warm-up time
3
20 min
3 dB cut-off frequency 500 Hz
Internal sample synchrony < 300 μs
External sample synchrony (ETH)
(Precision Time Protocol)
< 300 μs
1 Standard deviation at a sampling frequency of 5 Hz.
2 At wavelength 1552 nm and signal level 60 %.
3 Time between power-up and operation within specification
Requirements for sensors
Table 4: Requirements for sensors
Property Value Unit
Sensor type Fiber Bragg grating -
Reflectivity 70 ± 20 %
Full width half maximum (FWHM) 400 ... 600 pm
© fos4X 2020
MDE1195_4-10_1.3.x_5.0_Blackbird
OECD_(9CH, PRN)-en-us
13 / 76
