3. Product Description
The page FIRMWARE UPDATE displays the following information:
■
Current Firmware Version: Currently installed firmware version.
In the section Firmware Update the firmware of the Blackbird OECD can be
updated. See Firmware Update via Web Interface, page 66.
3.5.3 Signal Quality
The values for the signal quality have the following meanings:
■
Signal Good: Signal quality is good. Measurements are possible without
restrictions.
■
Signal Warning: There are one or more warnings. See Tab. 31: Signal Quality,
page 35. Measurements are possible. The measurements may be inaccurate
due to boundary effects and environmental conditions.
■
Signal Problem: There are one or more errors. See Tab. 31: Signal Quality,
page 35. Measurements are not possible.
Table 31: Signal Quality
Signal Quality Associated status codes
Signal Good -
Signal Warning
■
Temperature Low
■
Temperature High
■
Signal Level Low
■
Signal Level High
■
Wavelength Low
■
Wavelength High
