fos4X Blackbird OECD MDE1195 User Manual

3. Product Description
Property Value Unit
Max. Output rate 1000 Hz
Protocol TCP/IP -
3.2.3 Optical Data
Table 8: Optical Data
Property Value Unit
Connector type E-2000/APC -
Fiber type SMF 28 compatible -
Output power per channel (max.) < 10 mW
Output power per channel (typical) 0.5 ... 1 mW
Laser Class (DIN EN 60825-1) 1 -
3.2.4 Electrical Data
Table 9: Electrical Data
Property Value Unit
Power supply 10 … 28 V DC
Max. Power consumption 15 W
Electrical connector MC 1,5/ 2-GF-3,81
3.2.5 Environmental Conditions
Table 10: Environmental Conditions
Property Value Unit
IP protection class
*
IP20 -
Maximum operating altitude 3000 m
Permitted temperature
(Transport and storage)
-40 … +85 °C
© fos4X 2020
MDE1195_4-10_1.3.x_5.0_Blackbird
OECD_(9CH, PRN)-en-us
15 / 76
