Foster Solo Plus - Page 49

47
MODEL SP 3LC SP 4LC SP 4HC SP 5HC
Drawing No. Sheet No. 81802L 1 of 1
Drawn By Approved Date Sonchl Martinelli 04-12-1997
Rev No. Date: Approved
HVC Condenser Fan Motor K1 Compressor Contactor PHX High Pressure Switch HVE Evaporator Fan Motor H22 Internal Light BS Defrost Probe M1 Compressor EP Door Frame Heater (if fitted) BA Air Probe YS Hot Gas Solenoid Valve MP Door Switch (if fitted)
