Owner’s Manual Page 98Weather Covers - Section O
Secondary
Bow
Fwd Bimini
Main Bow
Bimini
Main Bow
Brace
Rod
Deck Mounts
Forward
Brace
Rod
Brace
Rod
Figure O-2: Forward Bimini & Bimini Top
C. Camper Canvas
The camper canvas is an option available on certain
Funship™models.Thecampercanvasencloses
the cockpit area and allows for overhead space. The
Funship™camperutilizestheaftbiminitopalongwith
other various canvas pieces. Covers roll up to expose
the window screens. See Figures O-3 and O-4. Your
Four Winns Dealer will gladly assist you with your
canvas selection as well as the installation.
Figure O-3: Camper Canvas
To install:
1. Install bimini top(s) as previously instructed.
2. Depending upon model, zip the side curtains and
forward connector or forward bow curtain to the
bimini top(s). Snap the bottom portion of these
curtains to either the top edge of the windshield
or the deck respectively.
3: Unroll the aft camper curtain and attach forward
edge of aft camper canvas to bimini zipper.
4. Depending on which the model you have either
snap the bottom portion of the aft curtain to the
transom and/or attach shock cords to deck.
4. Adjust the straps (if applicable) for tautness.
YoumaychoosetorunyourFunship™withthebimini
top either fully deployed or folded together (closed)
and secured with the boot provided. Either way it is
designed to remain mounted. No storage is provided
for this top in your boat.
NOTICE
Use two people to remove the bimini top (win-
ter storage). This will help minimize the risk of
injury and help prevent damage to the uphol-
stery, the bimini top, and/or the boat.
NOTICE
Aft/main bimini canvas deployment should only
be utilized at or below moderate cruising speed
(
approximately 0-40 mph). Avoid full throttle
operation of boat while having canvas de-
ployed. Four Winns recommends booting the
canvas before running at or close to maximum
speed. In so doing you will help to maintain the
life of the canvas and hardware. Also, the wind
should be taken into consideration when deter-
mining operating speed with canvas deployed.
The boat speed plus (+) wind speed should
not be exceed 40 mph.
B. Forward Bimini Canvas (certain models)
AforwardbiminitopisoptionalonsomeFunship™
models. The forward bimini provides shade for
persons occupying the bow area. The forward bimini
attaches to the standard rear bimini. See Figure O-2.
To install:
1. Attach the forward bimini main bow to the deck
mounts.
2
. Zip the forward bimini top to the aft bimini top.
3. Attach the forward brace rod to the deck mounts
located on the deck.
