Appendix 1: Data sheet
aGate
Model: aGate X
(1) Grid terminal (QF1 2P), Bi-directional:
Nominal AC Grid voltage (Vac) 120/240 V, (L1, L2, N)
Nominal AC Grid frequency (Hz) 60Hz
Nominal AC input/absorb current (Aac) 160A
Nominal AC input/absorb power (W) 38400W
Max. Continuous AC input/absorb power (VA) 38400 VA
Nominal AC output/inject to Grid current (Aac) 21A
Nominal AC output/inject to Grid power (W) 5000W
Max. Continuous AC output/inject to Grid current (Aac) 24.5A
Max. Continuous AC output/inject to Grid power (VA) 5800 VA
Output/inject power factor rating ±0.85, adjustable
Max. overcurrent protection (amps), circuit breaker ratings (QF1 2P) 200A
(2) AC input terminal, Diesel generator (QF2 2P):
Nominal AC input voltage (Vac) 240 V
Nominal AC input frequency (Hz) 60Hz
Nominal AC input current (Aac) 160A
Nominal AC input power (W) 38400W
Max. Continuous AC input current (Aac) 160A
Max. Continuous AC input power (VA) 38400 VA
Max. overcurrent protection (amps), circuit breaker ratings (QF2 2P) 200A
(3) AC output terminal, Non-Backup / L1, L2:
Nominal AC output voltage (Vac) 120/240 V, (L1, L2, N)
Nominal AC output frequency (Hz) 60Hz
Nominal AC output current (Aac) 160A
Nominal AC output power (W) 38400W
Max. Continuous AC output current (Aac) 160A
Max. Continuous AC output power (VA) 38400 VA
(4) AC output terminal, Backup / L1, L2:
Nominal AC output voltage (Vac) 120/240 V, (L1, L2, N)
Nominal AC output frequency (Hz) 60Hz
Nominal AC output current (Aac) 160A
Nominal AC output power (W) 38400W
Max. Continuous AC output current (Aac) 160A
Max. Continuous AC output power (VA) 38400 VA
(5) AC input terminal, PV converter’s output (QF3, 2P):
Nominal AC output voltage (Vac) 120/240 V, (L1, L2, N)
Nominal AC output frequency (Hz) 60Hz
Nominal AC input current (Aac) 64A
Nominal AC input power (W) 15360W
Max. overcurrent protection (amps), circuit breaker ratings (QF3 2P) 80A
