Appendix 1: Data sheet
aGate
(6) AC terminal (QF4 2P), Bi-directional:
Nominal AC output voltage (Vac) 120/240 V, (L1, L2, N)
Nominal AC output frequency (Hz) 60Hz
Nominal AC output/inject current (Aac) 21A
Nominal AC output/inject power (W), (L-N) 2500W
Nominal AC output/inject power (W), (L-L) 5000W
Max. Continuous AC output/inject current (Aac) 24.5A
Max. Continuous AC output/inject power (VA), (L-N) 2900 VA
Max. Continuous AC output/inject power (VA), (L-L) 5800 VA
Output/inject power factor rating ±0.85, adjustable
Max. overcurrent protection (amps), circuit breaker ratings (QF4 2P) 30A
(7) AC output terminal, Smart load 1, (QF5, 2P):
Nominal AC output voltage (Vac) 120/240 V, (L1, L2, N)
Nominal AC output frequency (Hz) 60Hz
Nominal AC output current (Aac) 40A
Nominal AC output power (W) (L-L) 9600W
Max. Continuous AC output current (Aac) (L-L) 40A
Max. Continuous AC output power (VA) (L-L) 9600W
Nominal AC output power (W) (L-N) 4800W
Max. Continuous AC output current (Aac) (L-N) 40A
Max. Continuous AC output power (VA) (L-N) 4800W
Max. output overcurrent protection (amps), circuit breaker ratings (QF5 2P) 50A
(8) AC output terminal, Smart load 2, (QF6, 2P)
Nominal AC output voltage (Vac) 120/240 V, (L1, L2, N)
Nominal AC output frequency (Hz) 60Hz
Nominal AC output current (Aac) 64A
Nominal AC output power (W) (L-L) 15360W
Max. Continuous AC output current (Aac) (L-L) 64A
Max. Continuous AC output power (VA) (L-L) 15360 VA
Nominal AC output power (W) (L-N) 7680W
Max. Continuous AC output current (Aac) (L-N) 64A
Max. Continuous AC output power (VA) (L-N) 7680 VA
Max. output overcurrent protection (amps), circuit breaker ratings (QF6 2P) 80A
Others:
Operation temperature range -20 ˚C to +50 ˚C
Enclosure Type Type 3R
Ingress protection IP44
Notes:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2)this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:—Reorient or relocate the receiving antenna.—
Increase the separation between the equipment and receiver.—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.—Consult the dealer or an experienced radio/TV technician for help.
77
