Chapter 3 List of Parameters
3.1 Standard Function Parameters
Table 3-1 Standard Function Parameters
Param.
Parameter Name
Instructions
Default
Attr
Group F00: System Parameters
F00.00
User Password
0～65535
0
×
F00.01
Display of Parameters
0: Display all parameters
0
×
1: Only display F00.00, F00.01
and user-defined parameters
F17.00～F17.29
2: Only display F00.00, F00.01,
and the parameters different with
factory default
F00.03
G/P type display
0: G type (constant torque load)
1
×
1: P type (variable torque load
e.g. fan and pump)
F00.04
Parameter Initialization
0: Invalid
0
×
1: Restore all parameters to
factory default (excluding motor
parameters)
2: Clear fault record
3: Restore user backup
parameters
4: Back up user parameters
5: Restore factory default(include
motor parameters)
6: Clear power dissipation
Group F01: Frequency Command
F01.01
Master Frequency
Command Source
0: Master digital setting (F01.02)
6
×
1: keypad potentiometer
2: Analog input AI1
3: Communication
4: Multi-reference
5: PLC
6: Process PID output
7: DI7/HI pulse input
8: Analog input AI2
9: Analog input AI3
F01.08
Maximum frequency
20.00～600.00Hz
50.00Hz
×
F01.09
Upper limit frequency
Fdown～Fmax
50.00Hz
×
F01.10
Lower limit frequency
0.00～Fu
0.00Hz
×
F01.11
Operation when
command frequency
lower than lower limit
frequency
0: Run at lower limit frequency
0
×
1: Run at 0 Hz would be
activated after the time delay set
by F01.12
F01.12
Lower limit frequency
running time
0.0～6000.0s
60.0s
×
Group F02: Start/Stop Control
F02.00
Run command
0: Keypad control (LED off)
1
×
1: Terminal control (LED on)
2: Communication control (LED
blinking)
F02.12
Stop mode
0: Ramp to stop
0
