Frecon FR200H - Status Monitoring and Fault Records

FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 20 -
3: AI3
F14.17
Wakeup Pressure
0.0%～Dormant Pressure
10.0%
△
F14.18
Dormant Pressure
Wakeup Pressure～100.0%
50.0%
△
Group U00 Status Monitoring
U00.00
Running frequency
0.00～Fu
0.00Hz
⊙
U00.01
Set frequency
0.00～Fmax
0.00Hz
⊙
U00.02
Output voltage
0～660V
0.0V
⊙
U00.03
Output current
0.0～3000.0A
0.0A
⊙
U00.04
Output power
-3000.0～3000.0kW
0.0kW
⊙
U00.05
Estimated Motor
Speed
0～60000rm
0rm
⊙
U00.06
Bus voltage
0～1200V
0V
⊙
U00.07
Synchronous Frequency
0.00～Fu
0.00Hz
⊙
U00.08
PLC step
1～15
1
⊙
U00.09
Program Operation
Time
0.0～6000.0s(h)
0.0s(h)
⊙
U00.10
PID set
0～60000
0
⊙
U00.11
PID feedback
0～60000
0
⊙
U00.12
Status of DI1～DI5
digital input terminal
DI5 DI4 DI3 DI2 DI1
00000
⊙
U00.13
Status of DI6～DI7
digital input terminal
DI7 DI6
00
⊙
U00.14
Status of digital output
terminal
R2 R1 Y2 Y1
0000
⊙
U00.15
AI1 input
0.0～100.0%
0.0%
⊙
U00.16
AI2 input
0.0～100.0%
0.0%
⊙
U00.17
AI3 input
-100.0～100.0%
0.0%
⊙
U00.18
Keypad potentiometer
input
0.0～100.0%
0.0%
⊙
U00.19
HI input
0.00～100.00kHz
0.00kHz
⊙
U00.20
AO1 output
0.0～100.0%
0.0%
⊙
U00.21
AO2 output
0.0～100.0%
0.0%
⊙
U00.22
HO output
0.00～100.00kHz
0.00kHz
⊙
U00.23
Temperature of inverter
-40.0℃～120.0℃
0.0℃
⊙
U00.24
Accumulative power-on
time
0～65535min
0min
⊙
U00.25
Accumulative running
time
0～6553.5min
0.0min
⊙
U00.26
Cumulative power-on
time
0～65535h
0h
⊙
U00.27
Cumulative running time
0～65535h
0h
⊙
U00.28
Count value
0～65535
0
⊙
U00.29
Length value
0～65535m
0m
⊙
U00.30
Linear speed
0～65535m/min
0m/Min
U00.31
Output torque
0.0～300.0%
0.0%
⊙
U00.32
Motor temperature by
PTC
-40℃～200℃
0℃
⊙
U00.33
Speed detected by
encoder
0～60000rpm
0rpm
⊙
U00.34
Encoder lines
0～65535
0
⊙
U00.35
Power dissipation
0～65535kWh
0kWh
⊙
U00.36
VDI1～VDI5 input state
VDI5 VDI4 VDI3 VDI2 VDI1
00000
⊙
