Frecon FR200H - Group F09 V;F Control Parameters of Motor 1

FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 15 -
asynchronous motor 1
defined
F08.12
No-load current of
async motor 1
0.1～1500.0A
Model
defined
×
F08.13
Field weakening coeff 1
of async motor 1
0.0～100.0
87%
×
F08.14
Field weakening coeff 2
of async motor 1
0.0～100.0
75%
×
F08.15
Field weakening coeff 3
of async motor 1
0.0～100.0
70%
×
F08.30
Autotuning of motor 1
0: No autotuning
0
×
1: Static autotuning of async
motor
2: Rotary autotuning of async
motor
Group F09 V/f Control Parameters of Motor 1
F09.00
V/f curve setting
00: LinearV/F
3
×
01: Multi-stage V/F
02: 1.2nd power V/F
03: 1.4th power V/F
04: 1.6th power V/F
05: 1.8th power V/F
06: 2.0nd power V/F
07: V/F complete separation
08: V/F half separation
09: 1.2 power inverse curve V/F
10: 1.4 power inverse curve V/F
11: 1.6 power inverse curve V/F
12: 1.8 power inverse curve V/F
13: 2.0 power inverse curve V/F
F09.01
Torque boost
0.0%–30.0% 0.0% (fixed
torque boost)
0.0%
△
F09.02
Cut-off frequency of
torque boost
0.00～Fmax
50.00Hz
△
F09.03
Multi-point V/F
frequency 1(F1)
0.00～F09.05
0.00Hz
△
F09.04
Multi-point V/F voltage 1
(V1)
0.0～100.0
0.0%
△
F09.05
Multi-point V/F
frequency 2(F2)
F09.03～F09.05
5.00Hz
△
F09.06
Multi-point V/F voltage 2
(V2)
0.0～100.0
14.0%
△
F09.07
Multi-point V/F
frequency 3(F3)
F09.05～F09.09
25.00Hz
△
F09.08
Multi-point V/F voltage 3
(V3)
0.0～100.0
50.0%
△
F09.09
Multi-point V/F
frequency 4(F4)
F09.07～rated motor frequency
50.00Hz
△
F09.10
Multi-point V/F voltage 4
(V4)
0.0～100.0 Ue=100.0%
100.0%
△
F09.11
V/F slip compensation
gain
0.0～300.0%
80.0%
△
F09.12
Stator voltagedrop
compensation gain
0.0～200.0%
100.0%
△
F09.13
Excitation boost gain
0.0～200.0%
100.0%
△
F09.14
Oscillation Suppression
0.0～300.0%
100.0%
△
