Frecon FR200H - Group F14: Swing Frequency, Fixed Length,Wakeup and Count

FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 19 -
2: Switched by terminal
F13.15
PID parameter
switchover
deviation 1
0.0～100.0%
20.0%
×
F13.16
PID parameter
switchover
deviation 2
0.0～100.0%
80.0%
×
F13.17
PID offset limit
0.0～100.0%
0.0%
×
F13.18
PID integral property
Unit's digit (Whether to stop
integral operation when the
output reaches the limit)
00
×
0: Continue integral operation
1: Stop integral operation
Ten's digit (Integral separated)
0: Invalid
1: Valid
F13.19
PID differential limit
0.0～100.0%
0.5%
×
F13.20
PID initial value
0.0～100.0%
0.0%
×
F13.21
Holding time of PID
initial value
0.0～6000.0s
0.0s
×
F13.22
PID output frequency
upper limit
PID output frequency lower
limit～100.0%（100.0%
corresponds to maximum
frequency ）
100.0%
×
F13.23
PID output frequency
lower limit
–100.0%～PID output frequency
upper limit
0.0%
×
F13.24
Detection value of
PID feedback loss
0.0～100.0%
0.0%: Not judging feedback loss
0.0%
×
F13.25
Detection time of
PID feedback loss
0.0～30.0s
1.0s
×
F13.26
PID operation at stop
Uinit’s digit:PID operation
0: No PID operation at stop
1: PID operation at stop
000
×
Ten’s digit:Output limit
0: Do not limit
1: limit
Hundred’s digit:PID digital given
by UP/DOWN
0: Clear to zero when power off
1: Preserve whenpower off
F13.27
UP/DOWN speed of PID
digital given
0.0~100% (0.0% valid)
0.0%
△
Group F14: Swing Frequency, Fixed Length ,Wakeup and Count
F14.10
Wakeup frequency
Dormant frequency (F14.12)～
Fmax
0.00Hz
△
F14.11
Wakeup delay time
0.0～6000.0s
0.0s
△
F14.12
Dormant frequency
0.00～Wakeup frequency
0.00Hz
△
F14.13
Dormant delay time
0.0～6000.0s
0.0s
△
F14.14
Wakeup Mode Selection
0: frequency wakeup
0
×
1: pressure wakeup
F14.15
Dormant Mode
Selection
0: frequency dormant
0
×
1: pressure dormant
F14.16
Pressure Feedback
Source
0: AI1
0
×
1: AI2
2: DI7/HI Pulse Input
