FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 18 -
reset
F11.28
Interval of automatic
reset
0.1～100.0s
1.0s
×
F11.29
DO action during fault
auto reset
0: Not act
0
×
1: Act
F11.30
Instant Power-failure
Bus Voltage
60.0％～Recovery Voltage
80%
F11.31
Instant Power-failure
Recovery Voltage
Power Failure Voltage～100.0％
85%
F11.32
Instant Power-failure
Voltage Adjustment
Time
0.01～10.00s
0.1
F11.33
Instant Power-failure
Gain K
0.1～100.0％
40.0%
F11.34
Instant Power-failure
Integral Time Ti
0.00～10.00s (0.00: Integral
Invalid)
0.1
Group F13 Process PID
F13.00
PID setting
0: F13.01 digital setting
2
×
1: keypad potentiometer
2: AI1
3: Communication
4: Multi-Reference
5: DI7/HI pulse input
6: AI2
7: AI3
F13.01
PID digital setting
0.0～100.0%
50.0%
△
F13.02
PID feedback
0: AI1
1
×
1: AI2
2: Communication
3: AI1+AI2
4: AI1-AI2
5: Max{AI1，AI2}
6: Min{AI1，AI2}
7: DI7/HI pulse input
8: AI3
F13.03
PID setting
feedbackrange
0～6000.0
100.0
△
F13.04
PID action direction
0: Forward action
0
×
1: Reverse action
F13.05
Filtering time of PID
setting
0.000～10.000s
0.000s
△
F13.06
Filtering time of PID
feedback
0.000～10.000s
0.000s
△
F13.07
Filtering time of PID
output
0.000～10.000s
0.000s
△
F13.08
Proportional gain Kp1
0.0～100.0
1.0
△
F13.09
Integration time Ti1
0.01～10.00s
0.10s
△
F13.10
Differential time Td1
0.000～10.000s
0.000s
△
F13.11
Proportional gain Kp2
0.0～100.0
1.0
△
F13.12
Integration time Ti2
0.01～10.00s
0.10s
△
F13.13
Differential time Td2
0.000～10.000s
0.000s
△
F13.14
PID setting
feedbackrange
0: No switch, determined by
parameters Kp1, Ti1 and Td1
0
×
1: Auto switch on the basis of
input offset
