FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 12 -
1: Coast to stop
F02.20
0Hz output selection
0:No-voltage output
0
×
1:Voltage output
Group F03: Accel/Decel Parameters
F03.00
Accel time 1
0.0～6000.0s
15s
△
F03.01
Decel time 1
0.0～6000.0s
15s
△
Group F04 Digital Input
F04.00
Function of terminal DI1
00: No function
01: Running forward (FWD)
02: Running reverse (REV)
03: Three-wire running control
04: JOG forward (FJOG)
05: JOG reverse (RJOG)
06: Coast to stop
07: Fault reset (RESET)
08: Running pause
09: External fault input
10: Terminal Up
11: Terminal DOWN
12: UP/DOWN (including ∧/∨
key) adjustment clear
13: Multi-step frequency terminal
1
14: Multi-step frequency terminal
2
15: Multi-step frequency terminal
3
16: Multi-step frequency terminal
4
17: Accel/Decel time determinant
1
18: Accel/Decel time determinant
2
19: Accel/Decel disabled(ramp
stop not inclusive)
20: Given frequency switching as
the auxiliary frequency source
21: PLC status reset
22: Simple PLC paused
23: ID paused
24: PID adjustment direction
25: PID integration paused
26: PID parameter switch
27: Swing frequency
pause(output the
currentfrequency)
28: Swing frequency reset(output
the central frequency)
29: Run command switched to
keypad control
30: Run command switched to
terminal control
31: Run command switched to
communication control
32: Count input
33: Count clear
34: Length pulse input
35: Length clear
1
×
F04.01
Function of terminal DI2
2
×
F04.02
Function of terminal DI3
7
×
F04.03
Function of terminal DI4
13
×
F04.04
Function of terminal DI5
0
×
F04.05
Function of terminal DI6
0
×
F04.06
Function of terminal DI7
0
×
