FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 13 -
36: DC brake input command at
stop
37:Speed/Torque control switch
38: Disable reverse
39: Disable forward
50: Special purpose inverter
enable
51: No.1 pump status
52: No.2 pump status
53: No.3 pump status
54: No.4 pump status
55: No.5 pump status
F04.13
Terminal DI1～DI5
positive/negative logic
DI5、DI4、DI3、DI2、DI1
00000
0: Positive logic(Terminals are on
at 0V/off at 24V)
1: Negative Logic (Terminals are
off at 0V/on at 24V)
F04.14
Terminal DI6～AI3
positive/negative logic
AI3、AI2、AI1、DI7、DI6
00000
0: Positive logic
1: Negative Logic
Group F05 Digital Output
F05.00
Y1 output function
00: No output
01: Drive is running
02: Fault output
03: Frequency-level detection
(FDT1)
04: Frequency-level detection
（FDT2）
05: Drive in 0Hz running 1 (no
output at stop)
06: Drive in 0Hz running 2(output
at stop)
07: Upper limit frequency
attained
08: Lower limit frequency
attained
09: Frequency attained
10: Inverter is ready to work
11: Drive (motor) overloaded
alarm
12: Inverter overheat warning
13: Current running time attained
14: Accumulative power-on time
attained
15: Consecutive running time
attained
16: PLC cycle completed
17: Set count value attained
18: Designated count value
attained
19: Length attained
20: Under-load warning
21: Brake output
22: DI1
23: DI2
30: No.1 pump power-frequency
control terminal
31: No.2 pump power-frequency
1
×
F05.01
Y2 output function
3
×
F05.02
Relay 1 output function
2
×
F05.03
Relay 2 output function
11
×
