FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 3 -
Chapter 1 Product Information
1.1 Nameplate information
Fig.1-1 Nameplate information
Model Explanation
Model show on product nameplate contains information below
FR200 H-4T-7.5G/011P B
Product series code:
FR200H
Input voltage:
2: 220V(-15%～+30%）
4: 380V(-15%～+30%）
Input voltage phases:
S:Single-phase
T:Three-phase
Industry-specific series
code H: special use for
multi-pumps constant
pressure water supply
Brake unit：
None: No Braking Unit
B: Built-in brake unit（30kW
following built，37 ~ 75kW optional
built，No built above 90kW）
Adaptable Motor (kW)And Type of
Motor：7.5G:7.5kW(General type）
011P:11kW(Fan pump type）
Figure 1-2 Product Model Number Naming Rule
