FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 14 -
control terminal
32: No.3 pump power-frequency
control terminal
33: No.4 pump power-frequency
control terminal
34: No.5 pump power-frequency
control terminal
35: No.1 pump
variable-frequency control
terminal
36: No.2 pump
variable-frequency control
terminal
F05.08
Enabled state of digital
output
Unit: Y1
0000
0: Positive Logic
1: Negative Logic
Decade: Y2 (same as unit)
Hundreds place: Relay 1 output
(same asunit)
Thousands place: Relay 2 output
(same as unit)
Group F07 Analog and Pulse Output
F07.00
AO1 output function
00: No output
1
×
F07.01
AO2 output function
01: Output frequency
2
×
F07.02
Y2/HO output function
(when used as HO)
02: Command frequency
1
×
03: Output current (rated current)
04: Output voltage(rated voltage)
05: Output power
06: Bus voltage
07: +10V
08: keypad potentiometer
09: AI1
10: AI2
11: AI3
12: HI (100% to 10.00kHz)
13: Output torque (torque
absolute value)
Group F08 Parameters of Motor 1
F08.01
Rated power of motor 1
0.10～600.00kW
Model
defined
×
F08.02
Rated voltage of motor 1
60～660V
Model
defined
×
F08.03
Rated current of motor 1
0.1～1500.0A
Model
defined
×
F08.04
Rated frequency of
motor 1
20.00～Fmax
Model
defined
×
F08.05
Rated speed of motor 1
1～30000
Model
defined
×
F08.07
The rated power factor
of async motor 1
0.50～0.99
Model
defined
×
F08.08
Stator resistance R1 of
async motor 1
0.001～65.535Ω
Model
defined
×
F08.09
Rotor resistance R2 of
async motor 1
0.001～65.535Ω
Model
defined
×
F08.10
Leakage inductance L1
of async motor 1
0.001～65.535mH
Model
defined
×
F08.11
Mutual inductance L2 of
0.1～6553.5mH
Model
×
