FR200H Special Purpose Inverters for Multi-pumps Constant Pressure Water Supply
- 16 -
F11.00
Current limit control
0: Current limit disabled
2
×
1: Current limit mode 1
2: Current limit mode 2
F11.01
Current limit
100.0～200.0%
150.0%
×
F11.02
Frequency decreasing
time(limit current in
constant speed
operation)
0.0～6000.0s
5.0s
△
F11.03
Current limit mode 2
proportion gain
0.1～100.0%
3.0%
△
F11.04
Current limit mode 2
integral time
0.00～10.00 s （0.00: integral
is invalid）
10.00s
△
F11.05
Overvoltage Stall
Control
0: Overvoltage stall disabled
1
×
1: Overvoltage stall mode 1
2: Overvoltage stall mode 2
F11.06
Overvoltage Stall
Voltage
600～800V(380V inverter)
320～400V(220V inverter)
730V
370V
×
F11.07
Overvoltage Stall
Mode 2 Proportion Gain
0.1～100.0%
50.0%
△
F11.08
Overvoltage Stall
Mode 2 frequency
limited
0.00～50.00Hz
5.00Hz
△
F11.10
Protection action 1
Unit's place: Bus undervoltage
03330
×
0: Fault reported and coast to
stop
1: Stop according to the stop
mode
2: Fault reported but continue
torun
3: Fault protection disabled
Ten's digit :Power input phase
Loss (Err09)(Same as unit's
place )
Hundred's digit :Power output
phase loss(Err10)(Same as unit's
place )
Thousand's digit:Motor
overload(Err11)(Same as unit's
place )
Ten thousand's digit:Inverter
overload(Err12)(Same as unit's
place )
F11.11
Protection action 2
External equipment fault（Err13)
00000
×
0: Fault reported and coast to
stop
1: Stop according to the stop
mode
2: Fault reported but continue
torun
Ten's digit: EEPROM read/write
fault (Err15) (Same as unit's
place)
Hundred's digit: Communication
overtime error (Err18) (Same as
unit's place)
Thousand's digit: PID feedback
