FreeStyle
®
series 2 wall mount gas-fired water boiler – boiler manual
37 Troubleshooting (continued)
Parameter Description Default Note
b01 Gas type selection (0=Natural Gas, 1=LPG) 0
b02
DHW conguration
2=Storage tank,
3=Instantaneous with secondary heat exchanger,
2 - Heating Only
3 - Combi
b03 Water pressure protection (0=Switch, 1=Sensor) 0
b04 Fan absolute DHW maximum speed (Hz)
See
Figure 128, page 101.
b05 Fan absolute CH maximum speed (Hz)
See
Figure 128, page 101.
b06 Fan absolute minimum speed (Hz)
See
Figure 128, page 101.
b07 Not implemented - DHW cong. 2
DHW maximum output boost/limit level (%) - DHW cong. 3
--
100
DHW conf. dependent
Do Not Adjust
b08 Not implemented - DHW cong. 2
DHW maximum output boost/limit time (Sec) - DHW cong. 3
--
60
DHW conf. dependent
Do Not Adjust
b09 Fan offset low level (Hz) 10 Do Not Adjust
b10 Summer/Winter function (0=Sum/Win, 1=always Win) 1 Do Not Adjust
b11 Variable input switch functionality (Number) 4 Do Not Adjust
b12 Variable output relay functionality (Number)
See
Figure 128, page 101.
Model dependent
b13 External pcb variable output relay functionality (Number) 7 Do Not Adjust
b14 Hours of no DHW ow to set the Economy mode (Hours) 24 Range=0-24 hours
b15 Fault F20 function (0=disable, 1=enable) 0 Do Not Adjust
b16 Maximum exhaust gases temperature (°F) 200
200 PVC/ 212 CPVC
sel. dependent
b17 Main supply frequency (0=50Hz, 1=60Hz) 1 Do Not Adjust
b18
Not implemented - DHW cong. 2
Not implemented - DHW cong. 3
--
--
DHW conf. dependent
Not used,
Do Not Adjust
b19 DHW tank prepare mode (Num.) - DHW cong. 2
DHW ow sensor lter (Sec) - DHW cong. 3
0
0
DHW conf. dependent
Do Not Adjust
b20 Fan type selection (0=Not used, 1=EBM) 1 Do Not Adjust
b21 Pump protection time (Sec) 5 Do Not Adjust
b22 PVC/CPVC/Polypro/AL29-4C Selection 1
See Options on page 34
b23 PVC maximum temperature (°F) 190 Do Not Adjust
b24 CPVC maximum temperature (°F) 200 Do Not Adjust
b25 Pre-purge time between A01 attempts 0 Do Not Adjust
b26 High altitude & Chimney length selection 0 Do Not Adjust
b27 Hydraulic conguration - DHW cong. 2
Not implemented - DHW cong. 3
0
--
DHW conf. dependent
Do Not Adjust
b28 Offset ame current low limit 20 Do Not Adjust
Figure 123 Conguration mode for FreeStyle
®
boilers — Parameters, Descriptions, Default displays and Notes
Conguration mode
By pressing the DHW- and DHW+ push buttons together for 10 seconds, it is possible to enter into the Conguration mode.
e display starts with showing “b01” blinking. By means of the CH “+” and CH “-” push buttons it is possible to select the
parameters; between “b01” and “b28”. Selecting one of these parameters, by means of the DHW “+” and DHW “-” push buttons
it is possible to adjust his value (not ashing). e value is automatically saved.
By pressing the DHW- and DHW+ push buttons together for 10 seconds, it is possible to leave the Conguration mode.
If no action has been taken, the MMI automatically leaves this mode aer 2 minutes.
