RWF ROTARY SCREW COMPRESSOR UNITS
MAINTENANCE
S70-600 IOM
Page 52
QUANTUM™ CONTROL:
Assembly, VGA Display, Phillips (Display only, 649C1078H01) 1 ALL 642C0052G01
Inverter, Sharp & Phillips (TDK) 1 ALL 333Q0001582
Power Supply 1 ALL 640C0022G01
Cable, CCFT Backlight Inverter (for Phillips Display) 1 ALL 649D4824H01
Keypad, Overlay 1 ALL 640D0060H01
Board, Analog 1 ALL 640C0026G01
Board, Digital 1 ALL 640C0024G01
Module, Output, 280V (For 115/230V) 2 ALL 111Q0281061
Module, Input, 90-140V (For 115V) 1 ALL 333Q0000116
Fuse, 5 Amp, 250V, I/O Board 4 ALL 333Q0001326
Relay, 3PDT, 115V 1 ALL 333Q0000206
Relay, 2PDT, 24VDC 1 ALL 333Q0001095
Fuse, 2 Amp, Quantum Panel 1 ALL 333Q0001672
UNIT:
Temperature Probe, Element Less Well (TE-1—4) 1 ALL 649A0994H01
Transducer, Pressure, 0—200 PSIA (PE-4) 1 ALL 913A0110H01
Transducer, Pressure, 0—500 PSIA (PE-1—3) 1 ALL 913A0110H02
Coil, 120V 60Hz, 110V 50Hz, Solenoid Valve 2 ALL 951A0092H04
Coil, 220V 50Hz, 240V 60Hz, Solenoid Valve 2 ALL 951A0092H05
Coil, 240V 50Hz, Solenoid Valve 2 ALL 951A0092H06
Seal Kit, Solenoid Valve 1 ALL 951A0056H34
Transmitter, Linear, Slide Valve (less well) 1 ALL 534D1251H03
Transmitter, Linear, Slide Stop (less well 1 ALL 534C1478H02
Heater, Oil, 500W, 120V 1 ALL 913A0092G01
Heater, Oil, 1000W, 120V 1 ALL 913A0092G02
Heater, Oil, 500W, 240V 1 ALL 913A0092G03
Heater, Oil, 1000W, 240V 1 ALL 913A0092G04
Filter, Coalescing, Convoluted A/R ALL 531B0065H01
Gasket, Manway For Coalescer 1 ALL 531A0105H04
Element, Oil Filter, SuperFilter™ (Required for 1-2-3 Warranty) A/R ALL 531A0218H01
Gasket, End Cover For 531A0218H01 Above A/R ALL 959A0082H01
Gasket, Clamping Plate For 531A0218H01 Above A/R ALL 959A0053H01
Seal, Center for 531A0218H01 Above A/R ALL 900A0007H01
Gasket, Bottom For 531A0218H01 Above A/R ALL 333Q0001236
Shaft Seal Replacement Kit 1 100 &134 534M0163G02
Shaft Seal Replacement Kit 1 177 - 270 534M0163G03
Shaft Seal Replacement Kit 1 316 - 480 534M0163G04
RECOMMENDED SPARE PARTS - CURRENT DESIGN
NOTE: This list is based on one unit. When stocking for more than one unit, the quantity should be adjusted to meet
your individual requirements.
