Friedrich Breeze Series User Manual

124 PB
13.SENSOR PARAMETER
T [℉
℉
] T [ ℃
℃
]
Rmin [ KΩ ] Rnom [ KΩ ] Rmax [ KΩ ] DR(MIN)% DR(MAX)%
66.2
19 71.2227 75.3122 79.3848
-5.43 5.13
68
20 68.1036 71.9808 75.8414
-5.39 5.09
69.8
21 65.1373 68.8141 72.4746
-5.34 5.05
71.6
22 62.3155 65.8032 69.2746
-5.30 5.01
73.4
23 59.6306 62.9395 66.2324
-5.26 4.97
75.2
24 57.0752 60.2152 63.3395
-5.21 4.93
77 25 54.6424 57.6227 60.5877
-5.17 4.89
78.8 26 52.3258 55.1551 57.9695
-5.13 4.85
80.6
27 50.1192 52.8058 55.4778
-5.09 4.82
82.4
28 48.0168 50.5684 53.1058
-5.05 4.78
84.2
29 46.0133 48.4371 50.8472
-5.00 4.74
86
30 44.1034 46.4046 48.6960
-4.96 4.71
87.8
31 42.2825 44.4711 46.6466
-4.92 4.66
89.6
32 40.5458 42.6261 44.6937
-4.88 4.63
91.4
33 38.8891 40.8668 42.8323
-4.84 4.59
93.2
34 37.3084 39.1890 41.0576
-4.80 4.55
95
35 35.7998 37.5883 39.3653
-4.76 4.51
96.8
36 34.3596 36.0609 37.7511
-4.72 4.48
98.6
37 32.9844 34.6030 36.2109
-4.68 4.44
100.4
38 31.6710 33.2113 34.7412
-4.64 4.40
102.2
39 30.4164 31.8823 33.3383
-4.60 4.37
104
40 29.2176 30.6130 31.9988
-4.56 4.33
105.8
41 28.0718 29.4004 30.7197
-4.52 4.29
107.6
42 26.9765 28.2417 29.4979
-4.48 4.26
109.4 43 25.9293 27.1342 28.3306
-4.44 4.22
111.2 44 24.9277 26.0755 27.2150
-4.40 4.19
113
45 23.9697 25.0632 26.1488
-4.36 4.15
114.8
46 23.0530 24.0950 25.1293
-4.32 4.12
116.6
47 22.1757 23.1688 24.1545
-4.29 4.08
118.4
48 21.3360 22.2826 23.2221
-4.25 4.05
120.2
49 20.5321 21.4345 22.3301
-4.21 4.01
122
50 19.7623 20.6226 21.4766
-4.17 3.98
123.8
51 19.0261 19.8468 20.6612
-4.14 3.94
125.6
52 18.3211 19.1040 19.8808
-4.10 3.91
127.4
53 17.6458 18.3926 19.1338
-4.06 3.87
129.2
54 16.9986 17.7113 18.4185
-4.02 3.84
131 55 16.3784 17.0537 17.7335
-3.96 3.83
132.8
56 15.7839 16.4332 17.0774
-3.95 3.77
134.6
57
●
15.2139 15.8338 16.4488
-3.92 3.74
136.4
58 14.6673 15.2592 15.8464
-3.88 3.71
138.2
59
●
14.1430 14.7083 15.2690
-3.84 3.67
140
60 13.6400 14.1799 14.7154
-3.81 3.64
141.8 61 13.1573 13.6730 14.1846
-3.77 3.61
143.6 62 12.6941 13.1868 13.6756
-3.74 3.57
145.4
63 12.2494 12.7202 13.1872
-3.70 3.54
147.2
64 11.8224 12.2723 12.7186
-3.67 3.51
149
65 11.4124 11.8424 12.2690
-3.63 3.48
150.8
66 11.0185 11.4295 11.8373
-3.60 3.45
152.6
67 10.6401 11.0331 11.4230
-3.56 3.41
154.4
68 10.2765 10.6522 11.0251
-3.53 3.38
156.2
69 9.9271 10.2863 10.6429
-3.49 3.35
158
70 9.5912 9.9348 10.2756
-3.46 3.32
159.8
71 9.2682 9.5968 9.9231
-3.42 3.29
161.6
72 8.9576 9.2720 9.5841
-3.39 3.26
163.4 73 8.6589 8.9597 9.2583
-3.36 3.23
165.2 74 8.3716 8.6594 8.9451
-3.32 3.19
53
APPENDIX
Appendix 3 Resistance Table for Compressor Discharge Sensor

Friedrich Breeze Series Specifications
