APPENDIX
Appendix 3 Resistance Table for Compressor Discharge Sensor
13.SENSOR PARAMETER
13. Sensor parameter
1.. The parameter of outdoor compressor discharge temperature sensor:
(R0=187.25K±6.3%；R
100
=3.77K±2.5K；B0/100=3979K±1%)
DR: Deviation Rate
DR(MIN)%=（Rmin-Rnom）/Rnom*100%
DR(MAX)%=（Rmax-Rnom）/Rnom*100%
Rmin [ KΩ ] Rnom [ KΩ ] Rmax [ KΩ ] DR(MIN)% DR(MAX)%
-22
-30 908.2603 985.5274 1065.1210
-7.84 7.47
-20.2
-29 855.3955 927.6043 1001.9150
-7.78 7.42
-18.4
-28 805.9244 873.4324 924.8368
-7.73 5.56
-16.6
-27 759.6097 822.7471 887.5944
-7.67 7.31
-14.8
-26 716.2320 775.3041 835.9165
-7.62 7.25
-13
-25 675.5881 730.8775 787.5529
-7.56 7.20
-11.2
-24 637.4902 689.2583 742.2720
-7.51 7.14
-9.4
-23 601.7645 650.2533 699.8601
-7.46 7.09
-7.6
-22 568.2499 613.6835 660.1191
-7.40 7.03
-5.8
-21 536.7970 579.3832 622.8658
-7.35 6.98
-4
-20 507.2676 547.1989 587.9307
-7.30 6.93
-2.2
-19 497.5332 516.9882 555.1565
-3.76 6.88
-0.4
-18 453.4748 488.6192 524.3977
-7.19 6.82
1.4
-17 428.9819 461.9693 495.5191
-7.14 6.77
3.2
-16 405.9517 436.9251 486.3954
-7.09 10.17
5
-15 384.2888 413.3808 442.9105
-7.04 6.67
6.8
-14 363.9047 391.2386 418.9563
-6.99 6.62
8.6
-13 344.7169 370.4072 396.4325
-6.94 6.56
10.4
-12 326.6497 350.8019 375.2461
-6.88 6.51
12.2
-11 309.6286 332.3441 355.3104
-6.83 6.46
14
-10 293.5903 314.9620 336.5448
-6.79 6.41
15.8
-9 278.4719 298.5822 318.3744
-6.74 6.22
17.6
-8 264.2156 283.1464 302.2294
-6.69 6.31
19.4
-7 250.7678 268.5936 286.5448
-6.64 6.26
21.2
-6 238.0783 254.8686 271.7603
-6.59 6.22
23
-5 226.1003 241.9200 257.8193
-6.54 6.17
24.8
-4 214.7903 229.6997 244.6593
-6.49 6.11
26.6
-3 204.1073 218.1630 232.2612
-6.44 6.07
28.4
-2 194.0135 207.2681 220.5495
-6.39 6.02
30.2
-1 184.4732 196.9759 209.4913
-6.35 5.97
32
0 175.4533 187.2500 199.0468
-6.30 5.93
33.8
1 166.8952 178.0255 189.1529
-6.25 5.88
35.6
2 158.8023 169.3067 179.8058
-6.20 5.84
37.4
3 151.1467 161.0633 170.9724
-6.16 5.80
39.2
4 143.9026 153.2667 162.6216
-6.11 5.75
41
5 137.0455 145.8905 154.7246
-6.06 5.71
42.8
6 130.5528 138.9097 147.2544
-6.02 5.67
44.6
7 124.4033 132.3011 140.1856
-5.97 5.62
46.4
8 118.5769 126.0429 133.4946
-5.92 5.58
48.2
9 113.0550 120.1146 127.1591
-5.88 5.54
50
10 107.8202 114.4973 121.1586
-5.83 5.50
51.8
11 102.8560 109.1728 115.4734
-5.79 5.46
53.6
12 98.1470 104.1246 110.0855
-5.74 5.41
55.4
13 93.6787 99.3367 104.9778
-5.70 5.37
57.2
14 89.4378 94.7946 100.1342
-5.65 5.33
59
15 85.4114 90.4842 95.5398
-5.61 5.29
60.8
16 81.5875 86.3926 91.1805
-5.56 5.25
62.6
17 77.9551 82.5076 87.0430
-5.52 5.21
64.4
18 74.5034 78.8177 83.1150
-5.47 5.17
T [℉
]
T [℃
]
