Friedrich Breeze Series User Manual

45 PB
INSTALLATION
Flow Chart
11.INSTALLATION TOOLS AND INSTALLATION FLOW CHART
11.2 Installation flow chart
Drawing audit
Preparation before installation
Confirm installation location of
indoor unit and outdoor unit
Indoor unit installation
Electrical wiring
Drain piping
installation
Duct installation
Refrigerant piping
installation
Heat insulation
Outdoor unit installation
Vacuum pumping and leakage
detection
Additional refrigerant charge
Test run
NOTE: This flow is only for reference; for details please see installation manual section.
