TROUBLESHOOTING
Diagnostic Codes ‑ Outdoor Unit
Fault
code
Fault description
Possible reasons for
abnormality
How to deal with Remarks
1
Outdoor ambient
temperature sensor fault
1. The outdoor ambient
temperature sensor is
connected loosely;
2. The outdoor ambient
temperature sensor fails to
work;
3. The sampling circuit fails.
1. Reconnect the outdoor
ambient temperature sensor;
2. Replace the outdoor
ambient temperature sensor
components;
3. Replace the outdoor
control board components.
2
Outdoor coil temperature
sensor fault
1. The outdoor coil temperature
sensor is connected loosely;
2. The outdoor coil temperature
sensor fails to work;
3. The sampling circuit fails.
1. Reconnect the outdoor coil
temperature sensor;
2. Replace the outdoor
coil temperature sensor
components;
3. Replace the outdoor
control board components.
3
The unit over‑current
turn off fault
1. Control board current
sampling circuit fails;
2. The current is over high
because the supply voltage is
too low;
3. The compressor is blocked;
4. Overload in cooling mode;
5. Overload in heating mode."
1. Replace the electrical control
board components;
2. Normal protection;
3. Replace the compressor;
4. Please see NOTE 3;
5. Please see NOTE 4.
4 EEprom Data error
1. EE components fails;
2. EE components control circuit
fails;
3. EE components are
inserted incorrectly."
1. Replace the EE components;
2 .Replace the outdoor control
board components;
3. Reassemble the
EE components.
5
Cooling freezing protection (the
indoor coil temperature is too
low) or heating overload (indoor
coil temperature is too high)
1. The indoor unit can not blow
air normally;
2. The room temperature is
too low in cooling mode or the
room temperature is too high in
heating;
3. The filter is dirty;
4. The duct resistance is too
high to resulting in low air flow;
5. The setting fan speed is too
low;
6. The indoor unit is not
installed in accordance with
the installation standards,
and the air inlet is too
close to the air outlet .
1. Check whether the indoor fan,
indoor fan motor and evaporator
work normally;
2. Normal protection;
3. Clean the filter;
4. Check the volume control
valve, duct length etc.;
5. Set the speed with high
speed;
6. Reinstall the indoor unit
referring to the user manual
to change the distance
between the indoor unit
and the wall or ceiling.
13
Compressor overheat
protector device
1. The wiring of the overload
protector is connected loosely.
2. The overload protector fails .
3. The refrigerant is not enough;
4. The installation pipe is much
longer than the normal one, but
extra refrigerant is not added ;
5. The expansion valve fails;
6. The outdoor control
board fails.
1. Reconnect the wiring of the
overload protector;
2. Replace the overload
protector;
3. Check the welding point of
the unit to confirm whether it is
leakage, and then recharge the
refrigerant;
4. Add the refrigerant;
5. Replace expansion valve;
6. Replace the outdoor
control board."
