Friedrich Breeze Series User Manual

128 PB
APPENDIX
Appendix 4 Resistance Table for Other Sensor
13.SENSOR PARAMETER
T [℉
℉
]
T [℃
℃
]
Rmin [ KΩ ] Rnom [ KΩ ] Rmax [ KΩ ] DR(MIN)%
DR(MAX)%
174.2
79 0.8570 0.9246 0.9971
-7.31 7.27
176
80 0.8316 0.8977 0.9687
-7.36 7.33
177.8
81 0.8071 0.8717 0.9412
-7.41 7.38
179.6
82 0.7834 0.8466 0.9146
-7.47 7.43
181.4
83 0.7604 0.8223 0.8888
-7.53 7.48
183.2
84 0.7382 0.7987 0.8639
-
●
7.57 7.55
185
85 0.7167 0.7759 0.8397
-7.63 7.60
186.8
86 0.6958 0.7537 0.8161
-7.68 7.65
188.6
87 0.6755 0.7322 0.7933
-7.74 7.70
190.4
88 0.6560 0.7114 0.7712
-7.79 7.75
192.2
89 0.6371 0.6913 0.7498
-7.84 7.80
194
90 0.6188 0.6718 0.7291
-7.89 7.86
195.8
91 0.6011 0.6530 0.7051
-7.95 7.39
197.6
92 0.5840 0.6348 0.6897
-8.00 7.96
199.4
93 0.5674 0.6171 0.6709
-8.05 8.02
201.2
94 0.5514 0.6000 0.6527
-8.10 8.07
203
95 0.5359 0.5835 0.6350
-8.16 8.11
204.8
96 0.5209 0.5675 0.6179
-8.21 8.16
206.6
97 0.5064 0.5519 0.6014
-8.24 8.23
208.4
98 0.4923 0.5369 0.5853
-8.31 8.27
210.2
99 0.4787 0.5224 0.5698
-8.37 8.32
212
100 0.4655 0.5083 0.5547
-8.42 8.36
213.8
101 0.4528 0.4946 0.5401
-8.45 8.42
215.6
102 0.4404 0.4814 0.5259
-8.52 8.46
217.4
103 0.4284 0.4685 0.5121
-8.56 8.51
219.2
104 0.4168 0.4561 0.4988
-8.62 8.56
221
105 0.4056 0.4440 0.4859
-8.65 8.62
222.8
106
0.3947 0.4323 0.4733 -8.70 8.66
224.6
107
0.3841 0.4210 0.4611 -8.76 8.70
226.4
108
0.3739 0.4100 0.4493 -8.80 8.75
228.2
109
0.3640 0.3993 0.4379 -8.84 8.81
230
110
0.3544 0.3890 0.4267 -8.89 8.84
231.8
111
0.3450 0.3789 0.4159 -8.95 8.90
233.6
112
0.336
●
0 0.3692 0.4055 -8.99 8.95
235.4
113
0.3272 0.3597 0.3953 -9.04 9.01
237.2
114
0.3187 0.3505 0.3854 -9.07 9.06
239
115
0.3104 0.3416 0.3758 -9.13 9.10
240.8
116
0.3024 0.3330 0.3665 -9.19 9.14
242.6
117
0.2947 0.3246 0.3574 -9.21 9.18
244.4
118
0.2871 0.3164 0.3468 -9.26 8.77
246.2
119
0.2798 0.3085 0.3401 -9.30 9.29
248
120
0.2727 0.3008 0.33 -9.34 9.34
