34 PB
5.CAPACITIES AND SELECTION DATA
Airflow
(CMF)
Outdoor
DB (°F)
IWB (°F) 59 63 67 71
IDB (°F) 70 75 80 85 70 75 80 85 70 75 80 85 70 75 80 85
1550
5
TC
37.2 37.7 38.4 38.9 38.4 38.9 39.3 39.8 41.2 41.5 41.8 42.1 \ 49.3 49.6 50.4
S/T
0.99 1.00 1.00 1.00 0.61 0.83 1.00 1.00 0.39 0.57 0.73 0.90 \ 0.39 0.53 0.67
kW
2.52 2.54 2.57 2.57 2.57 2.60 2.63 2.65 2.65 2.68 2.71 2.74 \ 3.20 3.23 3.06
30
TC
38.9 39.3 40.1 40.6 40.1 40.6 41.1 41.5 43.0 43.4 43.6 43.9 \ 51.5 51.8 52.6
S/T
0.99 1.00 1.00 1.00 0.61 0.83 1.00 1.00 0.39 0.57 0.73 0.90 \ 0.39 0.53 0.67
kW
2.80 2.83 2.85 2.85 2.85 2.89 2.92 2.95 2.95 2.97 3.01 3.04 \ 3.56 3.58 3.40
65
TC
40.9 41.4 42.2 42.7 42.2 42.7 43.2 43.7 45.3 45.7 45.9 46.3 \ 54.2 54.5 55.4
S/T
0.99 1.00 1.00 1.00 0.64 0.88 1.00 1.00 0.39 0.59 0.78 0.99 \ 0.38 0.55 0.71
kW
3.11 3.14 3.17 3.17 3.17 3.22 3.24 3.27 3.27 3.30 3.35 3.38 \ 3.95 3.98 3.78
75
TC
41.0 41.5 42.5 42.9 42.5 42.9 43.3 43.8 45.5 45.8 46.1 46.5 \ 55.5 55.8 55.9
S/T
0.99 1.00 1.00 1.00 0.63 0.88 1.00 1.00 0.39 0.59 0.78 1.00 \ 0.38 0.55 0.71
kW
3.20 3.23 3.27 3.27 3.27 3.30 3.33 3.38 3.38 3.41 3.44 3.48 \ 4.35 4.37 4.37
85
TC
40.2 40.7 41.5 42.0 41.5 42.0 42.4 42.9 44.6 44.8 45.2 45.4 \ 52.3 52.6 53.0
S/T
0.99 1.00 1.00 1.00 0.64 0.89 1.00 1.00 0.39 0.59 0.79 1.00 \ 0.39 0.56 0.73
kW
3.61 3.64 3.69 3.69 3.69 3.73 3.76 3.81 3.82 3.85 3.88 3.91 \ 4.65 4.69 4.72
95
TC
39.2 39.6 40.4 40.9 40.4 40.9 41.4 41.8 43.5 43.7 43.9 44.3 \ 49.8 50.0 50.0
S/T
1.00 1.00 1.00 1.00 0.64 0.90 1.00 1.00 0.39 0.60 0.80 1.00 \ 0.39 0.57 0.75
kW
4.25 4.29 4.34 4.34 4.34 4.38 4.42 4.47 4.50 4.53 4.56 4.59 \ 5.25 5.27 5.27
105
TC
38.1 38.5 39.3 39.8 39.3 39.8 40.2 40.7 42.2 42.5 42.7 43.1 \ 45.5 45.8 45.5
S/T
1.00 1.00 1.00 1.00 0.65 0.90 1.00 1.00 0.39 0.60 0.81 1.00 \ 0.39 0.59 0.79
kW
4.96 5.00 5.06 5.06 5.06 5.12 5.16 5.22 5.25 5.29 5.32 5.37 \ 5.52 5.55 5.46
115
TC
30.4 30.7 31.4 31.8 31.4 31.8 32.1 32.4 33.8 34.0 34.1 34.3 \ 36.3 36.4 36.5
S/T
1.00 1.00 1.00 1.00 0.66 1.00 1.00 1.00 0.40 0.66 0.93 1.00 \ 0.40 0.65 0.90
kW
●
4.38 4.42 4.48 4.48 4.48 4.53 4.57 4.62 4.68 4.69 4.72 4.73 \ 4.88 4.90 4.91
122
TC
25.9 26.1 26.7 27.0 26.7 27.0 27.3 27.5 28.8 28.9 29.0 29.2 \ 30.8 30.9 31.0
S/T
1.00 1.00 1.00 1.00 0.62 0.85 1.00 1.00 0.40 0.60 0.79 0.99 \ 0.39 0.58 0.76
kW
4.51 4.56 4.62 4.62 4.62 4.66 4.71 4.75 4.82 4.83 4.86 4.88 \ 5.03 5.04 5.06
Performance data (Heating operation at rated frequency)
48K outdoor unit matches 42K indoor unit
Airflow ID OD
75 65 55 47 35 25 15 5 -4 -13
1150
60
TC 49.5 49.5 49.4 47.4 40.3 37.5 33.7 29.2 25.5 19.1
kW 3.06 3.27 3.84 4.18 3.88 4.15 3.93 3.72 3.53 2.82
70
TC 38.3 38.0 38.1 37.7 37.7 36.8 33.2 28.7 25.0 18.8
kW 2.29 2.41 2.83 3.31 3.97 4.52 4.25 4.00 3.77 3.02
75
TC 32.2 32.1 32.1 32.1 31.6 31.6 31.5 26.9 22.8 17.1
kW 1.91 2.05 2.38 2.82 3.28 3.84 4.43 4.16 3.93 3.14
80
TC 26.4 26.4 26.4 26.3 26.2 25.9 25.9 25.9 22.4 16.8
kW 1.58 1.68 1.98 2.30 2.73 3.08 3.59 4.22 4.09 3.27
1350
60
TC 55.3 55.3 53.7 48.0 40.9 38.1 34.4 29.8 25.9 19.4
kW 3.62 3.83 4.25 4.09 3.84 4.12 3.91 3.72 3.55 2.84
70
TC 42.8 42.6 42.2 42.0 39.9 37.3 34.0 29.1 25.3 19.0
kW 2.64 2.82 3.24 3.73 4.19 4.46 4.22 4.00 3.80 3.04
75
TC 36.1 36.0 36.0 35.4 35.5 35.5 32.0 27.3 23.2 17.4
kW 2.22 2.36 2.76 3.14 3.76 4.42 4.40 4.15 3.94 3.15
80
TC 29.6 29.6 29.6 29.4 29.1 29.0 29.1 26.9 22.8 17.1
kW 1.82 1.94 2.26 2.61 3.04 3.53 4.09 4.33 4.09 3.27
1550
60
TC 61.6 60.6 54.7 48.9 41.5 38.7 34.9 30.3 26.4 19.8
kW 4.25 4.35 4.22 4.09 3.87 4.15 3.97 3.79 3.63 2.90
70
TC 47.3 47.2 47.2 47.1 40.6 37.9 34.3 29.7 25.8 19.4
kW 3.03 3.23 3.79 4.40 4.21 4.49 4.26 4.07 3.88 3.10
75
TC 40.3 40.2 39.7 39.6 39.6 37.4 32.6 27.8 23.8 17.9
kW 2.58 2.73 3.11 3.65 4.33 4.68 4.45 4.22 4.02 3.22
80
TC 33.2 33.1 33.1 32.9 32.5 32.5 32.1 27.4 23.3 17.5
kW
●
2.15 2.27 2.61 3.04 3.52 4.08 4.63 4.39 4.16 3.33
(CFM)
(°F)
(°F)
SPECIFICATIONS
Capacities and Selection Data frequency
